FTTH Drop Cable Production: Step-by-Step Manufacturing Process
Quick fact: over seventy percent of new broadband deployments in the U.S. now depend on fiber networks that need tight manufacturing control to hit performance targets.
Shanghai Weiye OFC Equipment handles complete SZ stranding line manufacturing, from selecting brand fibers like Fujikura® or Corning SMF-28e to complete test reports that ensure 100% quality assurance.
Our drop designs are built for overhead, ducted, and direct-buried installation, with low-smoke zero-halogen (LSZH), polyvinyl chloride (PVC), and PE jacket options and core counts from 1–4 cores. We offer single-mode OS1/OS2 and multimode OM2–OM4 grades plus ITU-T G.652D and ITU-T G.657 variants, Pantone-matched sheath colors, and logo printing.
Automated machines and precision equipment keep line speed steady and keep repeatability high. Typical lead times run four to five days for orders under 100 km and seven to ten days for < 500 km, with an MOQ of 1 km and free-replacement warranty for quality problems.
Keep reading to learn how materials plus testing and support work together to reduce lifecycle cost and match the right product to your network system.
- Shanghai Weiye OFC Equipment delivers end-to-end manufacturing and lab testing for United States projects.
- A range of jacket options and fiber grades cover different install environments.
- Automated lines and machines provide stable quality and reliable optical performance.
- Fast lead times, low minimums, and brand fiber options support reliable procurement planning.
- Comprehensive test reports and warranty support product reliability and compliance documentation needs.
Specialized FTTH Manufacturing by Shanghai Weiye OFC Equipment
When schedules and performance count, Shanghai Weiye OFC Equipment delivers customized drop cables with full test documentation.
As a dedicated manufacturer, Shanghai Weiye OFC Equipment pairs purpose-built equipment with tight material control. We offer customized service and products for residential/MDU deployments. Every order includes 100% quality assurance and complete test reports.
Our lab performs high heat, salt-fog, and vibration testing to validate durability. Jacket options cover LSZH, PVC, and PE. Designs include flat bow-type and figure-8/self-supporting styles and support brand fibers such as Fujikura® and Corning® SMF-28e.
- Controlled production lines and in-process checks for fully auditable shipments.
- Technical support for specs, trials, and ramp to volume.
- Modern fixtures and calibration minimize variation so every cable meets operator standards.
How We Produce FTTH Cable
At Shanghai Weiye OFC Equipment, manufacturing steps are aligned to network specifications, combining brand fiber choices with disciplined test flows.
Optical fiber selection and brand options
We select Fiber coloring machine to bend radius, attenuation, and install environment. Options include OS1, OS2, OM2–OM4 and ITU-T G.652D, G.657.A1/A2. Brand fibers such as Fujikura and Corning SMF-28e are offered to satisfy sourcing standards.
Integrating Strength Members
Strength members employ FRP (dielectric) or metallic steel wire. FRP is ideal where non-conductivity is necessary. Steel wire provides tensile strength for long-span aerial runs and bonding/grounding needs.
Jacket extrusion and process control
Jacket options include LSZH for flame/smoke safety, PVC for flexibility, and PE for UV/moisture resistance outdoors. Closed-loop control of temperature and capstan ratios stabilizes line speed and critical dimensions.
| Component | Dielectric FRP | Steel wire |
|---|---|---|
| Primary use | Electrical isolation | High-tension aerial runs |
| Advantage | Lightweight, inert | High strength |
| Installer note | Easier terminations | Requires grounding |
Inline and final testing
Inline geometry/concentricity checks operate in-line. Final optical tests confirm attenuation and return loss. Each order includes a full test report and lab results from high heat, salt fog, and vibration tests to qualify field handling and drop terminations.
Typical lead times are under 100 km in 4–5 days and 7–10 days for < 500 km. Lot records and FAI approvals support traceability and compliance for U.S. projects.
FTTH Drop Designs We Build
Shanghai Weiye OFC Equipment provides a focused portfolio of FTTH drop designs that cover tight indoor routes and exposed aerial spans. Each option pairs tested materials with geometry tuned for field termination and stable optical performance.
The bow-type flat drop cable keeps a small footprint for risers and conduit. It keeps bend loss low for simple routing in MDU corridors and hallways.
Self-Supporting Aerial Designs
Self-supporting FTTH drop designs include a support messenger to handle tension. Choose dielectric FRP for non-conductive runs or steel wire when bonding/grounding and extra tensile strength are required.
Layouts & Strength Members
We offer both dielectric and metallic strength member configurations to match safety and EMI rules. Center loose tube and unitube flat types balance crush resistance and compact fiber unit for quick termination.
Indoor vs Outdoor Jackets
Jacket choices include LSZH for flame-retardant, low-smoke indoor use and PE for outdoor durability. Each family is qualified for mechanical and optical quality before shipment.
| Design | Best use | Strength member | Sheath |
|---|---|---|---|
| Bow-type flat | Indoor risers, MDUs | Dielectric FRP | Low-smoke zero-halogen |
| Self-supporting | Aerial spans | Steel wire or FRP | Polyethylene |
| Center loose tube | Higher fiber counts | FRP | LSZH or PE |
| Flat unitube | Low-count, easy strip | FRP/Steel | LSZH or PE |
Equipment Ensuring Quality and Throughput
Automation and sensor-driven feedback at Shanghai Weiye OFC Equipment reduce manual handling and increase throughput for drop patch preparation.
Our production line uses automated machines that cut and strip drop patch cords to raise throughput and cut labor variability.
The CLX-BPO2 auto-stripping machine runs under PLC and photoelectric control. One cycle is about 1.5 seconds, giving ~20 terminals per minute in production.
Automated Cut/Strip for Drop Cords
The equipment strips LSZH/PVC jackets and trims FRP/steel members to precise stub lengths. Pneumatic cylinder actuators provide quick, repeatable motion and low downtime.
PLC/photoelectric control for precision and repeatability
PLC logic + photoelectric sensors deliver precise positioning and feedback control. Inline checks feed control charts so operators can adjust drifts before defects grow.
| Feature | Capability | Result |
|---|---|---|
| CLX-BPO2 | Auto-strip, ~1.5 s cycle | ~20 terminals/minute throughput |
| Drive | Pneumatic cylinders | Fast/reliable motion |
| Materials | LSZH & PVC; FRP & steel | Accurate stubs, clean terminations |
| Process control | PLC + photoelectric + inline checks | Consistent quality, lower rework |
- Auto scrap ejection and ergonomic loading maintain clean workcells.
- Process control plans document calibration and key parameters.
- Combined machines, fixtures, and trained staff help meet FTTH volume goals without compromising accuracy.
What the CLX-BPO2 Adds
The CLX-BPO2 provides industrial-grade strip/trim to our line, cutting cycle time while keeping prep consistent.
Shanghai Weiye OFC Equipment uses the CLX-BPO2 to increase throughput and standardize terminal quality. The unit cycles in ~1.5 seconds, yielding about 20 terminal preparations per minute in production.
PLC and photoelectric control deliver exact detection and repeatable actuation. That control helps keep strip lengths and reserved strength stubs within tight tolerances.
Cycle time and throughput
Typical operation speed is 1.5s per cycle. This enables steady throughput under normal production conditions.
Supported Strip and Stub Lengths
The CLX-BPO2 handles LSZH/PVC with an adjustable jacket strip length from 17.5 to 35.0 mm. Reserved stubs are adjustable from 7.0–11.0 mm to fit common termination hardware.
Cutting FRP/Steel Members
The machine cuts FRP/steel strength elements cleanly while protecting adjacent fibers. Customized cutters are available for non-standard cross-sections to preserve precision.
- Auto-eject scrap and sensor start cut idle time.
- Small footprint (L40 × W18 × H18 cm), 50W at 110–220V, and 11 kg weight simplify cell integration.
- Pneumatic cylinders and closed-loop control improve line reliability and lower maintenance interruptions.
| Specification | Rating | Benefit |
|---|---|---|
| Cycle | ~1.5 s (~20/min) | High throughput for production runs |
| Jacket strip (A) | 17.5 to 35.0 mm | Fits common connector processes |
| Stub (B) | 7.0 to 11.0 mm | Meets strength and termination needs |
| Power/Size | 110–220V, 50W; 40×18×18 cm | Simple integration |
Using this machine, Shanghai Weiye OFC Equipment standardizes terminal prep so field teams receive drop parts ready for quick installation. The CLX-BPO2 supports our lines in meeting volume targets without sacrificing quality.
Customized specifications to fit your FTTH system
Shanghai Weiye OFC Equipment configures each build to meet your network requirements and simplify deployment. We combine focused options with predictable schedules so your teams receive ready-to-install products.
Choose 1–4 core designs with SM or MM fiber. Options include OS1, OS2, and OM2–OM4 plus G.652D and G.657 variants to match your optics and connector plans.
We match sheath colors to Pantone codes for quick field identification and consistent asset tagging.
Jacket materials, print legends, and branding
Select LSZH, PVC, or PE jackets to suit route and safety requirements. Custom legends/logos support inventory and warranty tracking.
Put-Ups, Packaging, and Structures
Standard reel lengths are 1/2/4 km with custom reels and packaging to fit storage/handling. Choose bow-type flat or self-supporting designs and FRP or steel members to meet span and isolation needs.
| Choice | Typical | Advantage |
|---|---|---|
| Length | 1 / 2 / 4 km | Simpler staging and reels |
| Sheath | LSZH / PE / PVC | Indoor/outdoor compatibility |
| Design | Bow-type / Self-supporting | Routing and span flexibility |
As a supplier, Shanghai Weiye aligns runs to your schedule and delivers documentation that detail final specs for straightforward QA on site.
QA, Testing & Documentation
Shanghai Weiye OFC Equipment builds checkpoints into production so every item has recorded acceptance data at ship.
High-temperature, salt spray, and vibration laboratory testing
Our lab runs elevated-temperature exposure, salt spray corrosion, and vibration tests to qualify materials and assemblies. These tests recreate field stresses for indoor/outdoor applications.
Per-Reel 100% Reports
Every fiber optic cable includes a 100% test report that logs attenuation, return loss, and geometry where applicable. Final QC gates prevent nonconforming shipments before they leave the factory.
Traceability & Compliance
Lot/batch records link tests to reels/serials so audits and claims are easy to verify. Documentation follows common customer templates to speed approvals and inbound inspection.
- Line checks and final inspection reduce field failures and cut warranty events.
- Quality packages include spec confirmation and formatted test data for quick review.
- Continuous test trends inform preventive maintenance and improve long-term reliability.
| Test | Purpose | Result |
|---|---|---|
| Heat exposure | Thermal stability | Pass at target temperature |
| Salt spray | Corrosion resistance | Outdoor suitability |
| Mechanical vibration | Resistance to vibration | Reduced field failures |
FTTH Drop Cable Pricing & Cost Drivers
Budgeting for a drop run begins with fiber/jacket selection and is shaped by volume and customization.
Typical prices range broadly—from about $30–$1,000 per unit—based on fiber grade (G.652/G.657/OM2–OM4), jacket material, length, and structural design.
Primary Cost Inputs
The primary cost drivers are fiber optic grade, sheath material, and the chosen structure for deployment.
Self-supporting designs and steel members increase material/labor. Custom colors, logos, and print legends add setup time and influence price for short runs.
Length/Volume/Customization Impact
Longer put-ups and larger volumes lower unit cost. Short runs often carry setup fees and higher unit prices.
- Line changeovers and custom tooling increase lead time and add to cost.
- Clear RFQs with schedule alignment let Shanghai Weiye OFC Equipment align price quotes to delivery windows.
- Frameworks and indexed pricing stabilize budgets over phases.
| Driver | Price impact | Guidance |
|---|---|---|
| Fiber grade | High impact | Right-size spec to budget |
| Sheath material | Medium impact | Compare LSZH vs. PE for total cost |
| Order length / volume | Large | Consolidate runs to cut unit cost |
Lead times, MOQ, and delivery for the United States
Shanghai Weiye OFC Equipment makes lead times and logistics clear so planners can align crews and sites. Predictable windows cut downtime and help control cost when a rollout is underway.
Production Windows & Capacity
Typical production windows are 4–5 days for < 100 km and 7–10 days for < 500 km. We plan capacity to track your milestones and to maintain on-time delivery.
The service team provides updates/tracking so installation teams can plan arrivals. For tight schedules, we reserve contingency capacity to pull in critical-path orders.
MOQ and Rationale
The MOQ is one kilometer. This reflects setup needs such as wire and jacket die adjustments that consume start-up material and scrap.
We review your length and staging plans to select reels to reduce waste/handling. Batch releases can balance inventory with more frequent small-site deliveries.
Installation readiness and application scenarios
On-site conditions dictate whether a self-supporting span, ducted pull, or direct burial is the best fit for a project.
Deployment Considerations
For aerial runs, Shanghai Weiye OFC Equipment recommends self-supporting designs with correct strength members to manage sag/tension for long-term reliability.
Duct installations work best with low-friction sheaths and crush-resistant builds so pulling avoids fiber damage. PE jackets are common for underground and buried paths where moisture resistance matters.
Direct-buried designs need correct burial depth per local codes and moisture-resistant jackets to protect the optic core over time.
Indoor riser/plenum distribution and ONT termination
Indoor riser and plenum routes prefer LSZH to meet smoke/flame codes. Flat drop cable forms strip cleanly and present controlled strength stubs for quick ONT termination.
We advise on steel vs FRP (dielectric) strength members based on bonding requirements, lightning risk, and hardware fit. Standardized line prep shortens install time and minimizes scrap.
| Deployment | Key feature | Installer note |
|---|---|---|
| Aerial | Self-supporting, steel or FRP | Verify messenger hardware/tension |
| Underground duct | Low-friction jacket, crush resistance | Use pull tape + lubricant |
| Direct-buried | PE with moisture barrier | Follow depth/warning tape codes |
| Indoor | LSZH jacket, tight bend support | Maintain bend radius at penetrations |
Our approach ensures a consistent install experience across indoor outdoor transitions. That leads to fewer callbacks, speeds activations, and stable field performance for your system.
End-to-end support and after-sales service
Our team coordinates testing, scheduling, and installation guidance to avoid surprises in deployment.
Shanghai Weiye OFC Equipment provides engineering support from early requirements capture through approved drawings and pilot builds. We deliver documentation templates and clear installation notes so field crews share a unified plan.
After-sales service covers rapid response, root-cause analysis, and corrective actions. All products ship with full reports and traceability to help QA acceptance.
- 24/7 availability for status updates and technical guidance.
- Warranty includes free replacement for confirmed quality issues.
- Schedule coordination for expedites and urgent changes.
- Config control so shipped items match agreed requirements every time.
| Area | What we do | Benefit |
|---|---|---|
| Tech/Eng | Specs + pilots | Reduced field issues |
| Testing | Lab trials & 100% test reports | Full traceability |
| Service | Rapid replacement & root-cause | Lower downtime |
Wrap-Up
Choose Shanghai Weiye OFC Equipment for tailored drop builds, short lead times, and traceable quality records.
We deliver customized FTTH drop solutions that combine materials with validated manufacturing and lab tests. Every reel includes a 100% test report and documented lab trials to support U.S. field acceptance.
A robust production line, including CLX-BPO2 prep assets, reduces variability and speeds turnaround. Our equipment set standardize strip/stub lengths so installers get consistent results at turn-up.
From fiber selection to jacket, printing, and packaging, we balance design and cost to extend service life. Dedicated support covers scheduling/logistics/after-sales so your deployment stays on plan.
Contact Shanghai Weiye OFC Equipment to align specs, timeline, and volume. We stand behind every shipment with lab validation and responsive service.
